Zenitel ACM-M-D-V2

Zenitel ACM-M-D-V2
Telephone exchange ACM-M-D-V2 is designed specifically for use on ships. However Vingtor-Stentofon SPA, the system is extremely cost-effective, it acoustic loop SPA used in conjunction with the ACM negotiating terminals, to cover all areas on board. In a telephone ACM-M-D-V2 station uses 1-bit digital audio technology (18.5 kHz). Installation is easy access to all terminals.

Zenitel ACM-M-D-V2


Service PBX ACM-M-D-V2 is very user-friendly. The switch is mounted in a steel rack, providing easy access to the terminal blocks on the rear side of the rack. System approved by DNV, Rina, CCS and CRS as an embedded communication system for two-way communication, notification (PA) and general alarm (GA). Perhaps AlphaPro remote system management via IP-based networks.

Specifications:
  • Size: 600 x 600 x 350 mm
  • Weight - 45 kg
  • Mounting - wall
  • Operating temperature range: 0 - 55 ° C, it recommended 18 - 25 ° C
  • Powered by AC 230 V with automatic switching to the UPS 230 V AC or 24 V DC emergency power
  • IP: IP 22 class
  • IP broadband audio (8 kHz) - adaptive jitter buffers
  • Data interface: 2 x 10/100 Mbps Ethernet Auto MDIX (RJ45) 1 x RS232 serial data (RJ45)
  • Data network: 4-port switch



Available for order

Zenitel ACM-M-D-V2

to order
Call our sales manager
Documentation:
ACM-M-D-V2
ACM-M-D-V2
