Alarm block
Description:
An alarm unit providing audio and visual warnings in case of:
- Loss of voltage on the monitored line;
- Receipt of a dry contact emergency signal.
The device features four operating modes and can monitor:
- 24 VDC voltage;
- 230 VAC voltage;
- Dry contact (NO/NC) alarm input status.
Operating mode: In alarm mode, the unit emits short audible beeps and flashes the LED built into the acknowledgment button.
The operating mode is selected via the switches under the unit’s cover:
1. 24V DC power monitoring mode – Alarm triggered when 24V DC is lost at input X2.
2. 230V AC power monitoring mode – Alarm triggered when 230V AC is lost at input X2.
3. Normally Open (NO) dry contact input mode – Alarm triggered when a short circuit occurs between the "+" and "-" terminals at input X2.
4. Normally Closed (NC) dry contact input mode – Alarm triggered when an open circuit occurs between the "+" and "-" terminals at input X2.
- Loss of voltage on the monitored line;
- Receipt of a dry contact emergency signal.
The device features four operating modes and can monitor:
- 24 VDC voltage;
- 230 VAC voltage;
- Dry contact (NO/NC) alarm input status.
Operating mode: In alarm mode, the unit emits short audible beeps and flashes the LED built into the acknowledgment button.
The operating mode is selected via the switches under the unit’s cover:
1. 24V DC power monitoring mode – Alarm triggered when 24V DC is lost at input X2.
2. 230V AC power monitoring mode – Alarm triggered when 230V AC is lost at input X2.
3. Normally Open (NO) dry contact input mode – Alarm triggered when a short circuit occurs between the "+" and "-" terminals at input X2.
4. Normally Closed (NC) dry contact input mode – Alarm triggered when an open circuit occurs between the "+" and "-" terminals at input X2.
Power supply voltage | 9-36 VDC |
Power consumption | ≤ 2 W |
Galvanic isolation from power supply | Yes |
Reverse polarity protection | Yes |
Number of input ports | 1 |
Input signal types | 24VDC, 230VAC, Dry contact (NO/NC) |
Galvanic isolation of inputs | Yes |
Storage temperature | -55°C to +75°C |
Operating temperature | -30°C to +55°C |
Protection class | IP 22 |
Dimensions (W×H×D) | 115x116x55 mm |
Weight | 0.53 kg |
